Fiber Distribution Box

Accommodated 1*16 PLC splitter



Overview

FDB-16 Series 16 ports Fiber Distribution Box, also called Splitter Distribution Box or Fiber Terminal Box, can be used in FTTH projects and is suitable for corridor, basement, room, and building’s outer walls application. With the function of the mechanical splice, fusion splice, light splitting, and wiring distributions. It can accommodate 1×16 PLC splitter. The fiber access terminal box is with Anti-UV, Ultra violet resistant, rainfall resistant, IP65 waterproof design, and can be installed outside.



Features

• Industry Standard User Interface, be made of high impact plastic.
• Can accommodate 1×16 PLC splitter.
• Anti-UV, Ultra violet resistant, and rainfall resistant.
• Up to 16 FTTH drops.
• Wall and pole mountable.
• 2 inlet ports, 16 outlet ports.
• IP65 waterproof and dust-proof plastic case



Application

• Widely used in FTTH access network.
• Telecommunication Networks
• CATV Networks
• Data communications Networks
• Local Area Networks



Order Information

Model	Dimension	Max.Capacity	Note
FDB-16	260*320*90mm	16 ports & splice	Wall/Pole mount
